LODESTAR® D8+ Electric Chain Motor

The Lodestar D8+ electric chain motor meets all Standard SR2.0 requirements. It’s clutch, outside the load path, acts as a precise overload device; and design factor is 10:1 with a double brake installed. The Lodestar D8+ is in accordance with the VPLT Code of Practice.

CMET Entertainment Technology | XSFTRUSS

Columbus McKinnon Entertainment Technology (CM-ET) is the entertainment industry leader in providing quality lifting and positioning equipment for riggers around the globe.

FEATURES & BENEFITS

8:1 MECHANICAL DESIGN FACTOR

ELECTRO-MECHANICAL DOUBLE BRAKES

5 POCKET LIFT WHEEL
For quiet & smooth operation.

68 DB OPERATIONAL NOISE
A result of the Double Brake System

GEARING
Precision machined gears heat treated for strenght and durability.

INTERNAL CHAIN GUIDE
PVC black coated for quieter operation.

LOW VOLTAGE CONTROL
110 Volt for long cable runs without voltage drop.
24 & 48 Volt optional

DUTY CYCLE
H-4 duty rated for heavy duty application.
2M+ FEM class. 50% Duty Cycle or 300 on/off per hour.

IP54 PROTECTION CLASS

73DB NOISE LEVEL

OVERLOAD PROTECTION
Rated operational range between 125 and 150/160%. Clutch is outside the load path when disconnected from power.

DURABLE & LIGHTWEIGHT HOUSING
Cast aluminum. Black powder coated finish for low visibility.

METRIC RATED LOAD CHAIN
Designed and manufactured by Columbus McKinnon. Zinc plated to protect against corrosion. Black phosphate finish optional.

THE INDUSTRY’S BEST LIFETIME WARRANTY

MEETS OR EXCEEDS WORLD STANDARDS
Meets all Standard VPLT SR2.0/SQPR requirements.

CHAIN STOP
Mounted on load chain to prevent over-travel. Standard on all Lodestars.

CM-Lodestar D8 Chain Hoist
OPTIONAL FEATURES

EASY TO MOUNT CLOTH TYPE CHAIN BAG

CHAIN STOP
Mounted on load chain to prevent over-travel. Standard on Direct Control.

-LODESTAR CHAIN HOIST ROAD CASES -

1/2" PLYWOOD CONSTRUCTION

  • Kangaroo Cases are sturdy and unyieldingly solid. They have an added Black ABS Laminate exterior with a ¾” castor board that provides smooth, controlled and confident movement.

TOUGH 4 - 4" BLUE CASTERS ( with red upgrade option)

  • Built for the road they add a seamless easy ground roll.

LARGE RECESSED HEAVY DUTY HARDWARE

  • High Quality Hardware with recessed lid Stops/Hinge.

CUSTOM DESIGNED COMPARTMENTS

  • Designed for Lodestar and Prostars motors with V-cut chain passages, chain storage, and bag storage.
